3-speed gearbox with transfer case and self-locking differential
317,90 €
incl. 19% VAT plus Shipping
3-speed gearbox with transfer case, permanent four-wheel drive, self-locking differential to compensate for the speed differences in the drive train, gear housing made of aluminum, hardened gears made of steel, 10-times ball bearing, suitable for the scale 1:16 – 1:10, reductions: 1st gear 22.65: 1, 2nd gear 11.32: 1, 3rd gear 5.66: 1. Dim. Length without motor 80mm, width 46.6mm, height 64mm, The output shafts have a diameter of 5mm.
The gears are switched by a servo. The gearbox is mounted, the max. Input speed is 6,500 rpm. The attachment to the frame via the existing brackets on the transmission housing. The frame width should be between 60-63mm.
Contents: 1 manual gearbox with distributor, fixing screws, linkages
item code: 251106
Warning! Not suitable for children under 14 years.
In stock
3-speed gearbox with transfer case, permanent four-wheel drive, self-locking differential to compensate for the speed differences in the drive train, gear housing made of aluminum, hardened gears made of steel, 10-times ball bearing, suitable for the scale 1:16 – 1:10, reductions: 1st gear 22.65: 1, 2nd gear 11.32: 1, 3rd gear 5.66: 1. Dim. Length without motor 80mm, width 46.6mm, height 64mm, The output shafts have a diameter of 5mm.
The gears are switched by a servo. The gearbox is mounted, the max. Input speed is 6,500 rpm. The attachment to the frame via the existing brackets on the transmission housing. The frame width should be between 60-63mm.
Contents: 1 manual gearbox with distributor, fixing screws, linkages
Warning! Not suitable for children under 14 years.
| Weight | 0,5 kg |
|---|---|
