3-speed gearbox with transfer case

3-speed gearbox with transfer case, for all-wheel drive, gearbox housing made of aluminum, hardened steel gears, 8-way ball bearings, suitable for the scale 1/16 to 1/10, reductions: 1st gear 22,65: 1, 2nd gear 11.32: 1, 3rd gear 5.66: 1. Dim. without motor 80mm, width 46.6mm, height 64mm, The output shafts have a diameter of 5mm.

The front axle can be switched on with a servo. The gears are switched by a second servo. The gearbox is mounted, the max. input speed is 6,500 rpm. The attachment to the frame via the existing brackets on the transmission housing. The frame width should be between 60-63mm.

Contents: 1 manual gearbox with distributor, fixing screws, linkages

Item code: 251105
