Spindle drive for Fliegl Stone Master
Spindle drive for Fliegl Stone Master, the toggle pin "Z bar" for the motorized drive of the trough gives the CARSON 3-axle dump trucks Fliegl Stone Master (Item code 907216) a more prototypical function. For Operating a geared motor No. 907166 required.
Technical specifications: Material aluminum with steel bolts / shafts
item code : 907217
3-axle dump trucks Fliegl Stone Master
3-axle dump trucks Fliegl Stone Master
The 3-axle dump trucks Fliegl Stone Master is an accurate and licensed replica of a current lap tray (halfpipe) for use on construction sites. With the optional tilt mechanism the trough can be tilted and discharged. When lowering the rear wall of the trough is automatically saved with the 2-hook locking.
The kit is equipped with a steel frame and a steel trough including the back wall, an ABS working platform, semicircular ABS fenders, king pin, height-adjustable support legs, true to the original air suspension dummies and a ball bearing set. The 7-chamber tail lights of CARSON 3-axle dump truck Fliegl Stone Master electrically retrofitted.
Technical details:
Trough (CNC bent) and rear wall made of 2 mm sheet steel (laser-cut and 5 axis laser welding · Suspension of plastic with Luftbalgattrappen · 1 mm and 3 mm steel frame (chassis) laser cut · 12 ballraces · 6-trailers rims wide x 6 Fulda Multitonn 2 wide tires for semi-trailer rims · 7-chamber tail lights · license plate holder illuminated · plastic fenders half round with holder · Automatic 2-hook back lock · 4kant aluminum underbody protection CNC machined · trailer supports mechanically adjustable · platform / podium plastic · Hydraulic cylinder dummy
Optional retrofit parts
Tilting spindle drive No. 907217
Motor for spindle drive No. 907166
Motorized support legs No. 907218
Motor for trailer supports No. 907199 - required 2x
item code : 907216
Alu – flat bed twin rim
Fender semi-circular, plastic
Idler
Sprocket 19 teeth
MB Actros top light holder with chromed lights
MB Actros top light holder with chromed lights, scale 1/14, only for the MB Actros from Tamiya. The light holder is formed from brass and chrome, the lights are from plastic and chrome-plated, you can retrofit them with bulbs, 4 clear and 4 blue glasses and the fixing srews are included, measure: width ca. 130mm , length ca. 100mm, Quantity: 1 piece
Item code : 907134
HELLA FLASHING LIGHT BLUE, ADJUSTABLE + / – 5 °
Hella flashing light blue, scale 1/14, for roof mounting, adjustable + / - 5 °, 7 blue SMD's, 4.5 to 13.5 volts, 13 selectable programs, 6-round and 7 flash modes, aluminum housing, 4 different glasses for exchange, dim. : Total height approximately 22mm, 17mm diameter disc, diameter glass 11mm, cable length 250mm, capacity: 1 Housing with electronics, 1 slice, 4 glasses, mounting hardware, instructions
Licensed by Hella
item code : 907582
HELLA FLASHING LIGHT BLUE, FOR VERTICAL MOUNTING
Hella flashing light blue, scale 1/14, for vertical mounting, 7 blue SMD's, 4.5 to 13.5 volts, 13 selectable programs, 6-round and 7 flash modes, aluminum housing, 4 different glasses to share information, dim. : Overall height 28mm, diameter 12mm, 4mm diameter pin, cable length 250mm, capacity: 1 Housing with electronics, 4 glasses, instructions
Licensed by Hella
item code : 907581
Video with technical details
MAN headlight board 12V
MAN headlight board, 12V, the following light functions: turn signals, parking lights, fog lights, headlights, driving lights, cornering lights, suitable for the MAN from Tamiya, contents: 1 right board, 1 left board, instructions
Caution! Not suitable for children under the age of 14.
Attention : Not suitable for the MFC from Tamiya
item code : 907392
MAN headlight board 7,2 Volt
MAN headlight board 7,2 Volt, following light functions : turn signal, parking light, fog light, high beam, driving light, cornering light , suitable for the MAN from Tamiya, content : 1 right board, 1 left board, manual.
Attention : Not suitable for the MFC from Tamiya
Caution! Not suitable for children under the age of 14.
item code: 907391
